Mondraker Crafty Carbon R

Mondraker Crafty Carbon R

Mondraker Crafty Carbon R e-Bike with Bosch Performance Line CX Cruise (25Km/h) Bosch Smart System.

You’re one of those riders who enjoys going up, but what you really, really love are the flowy trails on the way back down, taking full advantage of everything ridable in the area. You live every second of the ride, pushing your limits as far as you can, and when you get to the bottom, that buzz as you tell your mates about that curve you nailed, that jump that you have been wanting to clear forever and which at last you finally sent ... Without a doubt you’re one us, you have Mondraker DNA, and we love that! That’s why our Enduro and All Mountain bikes offer you our Forward Geometry, our Zero Suspension System, and MIND technology to let you set up your suspension absolutely perfectly. And best of all yet, is that with any one of them you’ll feel like the most amazing rider on the planet.

Features 150mm rear travel with 160mm fork travel for a fully capable E-assist mountain bike for everyday trail riding as well as trips to the mountains and bike parks.





Lead time: PLEASE CONTACT FOR AVAILABILITY
Price (select options)
$9,306.45
e: / t: 01323 737320

THE DETAIL

Stealth Air Carbon Structure

NEW Zero Kinematics

Forward Geometry

One-piece Monoblock upper link

Hidden housing guide through headtube

Double row Enduro Sealed bearing

Integrated Rear Shock Fender

NEW charging point location

NEW dropout for slim speed sensor

NEW Fidlock integrated pocket

Frame also features the following:

Post Mount 180mm/Tapered head tube/ISCG05/Custom Chainguide/Custom frame rubber protectors/Fidlock Integration Pocket/Boost

1/9
2/9
3/9
4/9
5/9
6/9
7/9
8/9
9/9

SPECIFICATIONS

Build Crafty Carbon R
Frame Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Fork Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Shock Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings, Medium compression, medium rebound, air volume spacer 0.2
Chain Guid
Rear Derailleur SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shifters SRAM Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Crankset Race Face Aeffect ebike, 165mm, SRAM X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
Cassette SRAM XG-1230, 11-50T, 12s
Chain SRAM NX Eagle, 12s, Powerlock
Brakes SRAM G2 RS, SwingLink and lever pivot bearings, tools-free reach and contact point adjust, 4-piston caliper, steel-backed organic pads
Rotors Centerline 200mm IS 6 bolts one-piece rotor
Handlebar ONOFF Krypton 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9deg backsweep, 5deg upsweep, 31.8mm barbore
Stem ONOFF Krypton FG 30mm, CNC, 31.8mm barbore
Grips ONOFF Diamond, 1lock-on, 135mm
Headset Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
Seatpost ONOFF Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
Saddle FIZIK Terra Aidon X5 145mm
Front Tyre Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Rear Tyre Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Wheels Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 Mavic J-bend duble butted spokes, contactless lacing, Mavic, Boost 15x110mm, IS 6 bolts Front hub, Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
Drive Unit Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3
Battery Bosch Powertube 750Wh
Display Bosch Kiox 300
Weight 23.7KG
Build Crafty Carbon R
Frame Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Fork Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Shock Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings, Medium compression, medium rebound, air volume spacer 0.2
Chain Guid
Rear Derailleur SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shifters SRAM Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Crankset Race Face Aeffect ebike, 165mm, SRAM X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
Cassette SRAM XG-1230, 11-50T, 12s
Chain SRAM NX Eagle, 12s, Powerlock
Brakes SRAM G2 RS, SwingLink and lever pivot bearings, tools-free reach and contact point adjust, 4-piston caliper, steel-backed organic pads
Rotors Centerline 200mm IS 6 bolts one-piece rotor
Handlebar ONOFF Krypton 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9deg backsweep, 5deg upsweep, 31.8mm barbore
Stem ONOFF Krypton FG 30mm, CNC, 31.8mm barbore
Grips ONOFF Diamond, 1lock-on, 135mm
Headset Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
Seatpost ONOFF Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
Saddle FIZIK Terra Aidon X5 145mm
Front Tyre Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Rear Tyre Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Wheels Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 Mavic J-bend duble butted spokes, contactless lacing, Mavic, Boost 15x110mm, IS 6 bolts Front hub, Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
Drive Unit Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3
Battery Bosch Powertube 750Wh
Display Bosch Kiox 300
Weight 23.7KG
