Mountain Bike Wheelset 29

The EX 511 mountain bike rim benefits from technologies that have resulted in multiple racing victories at the Enduro World Series. Ready to ride burlier and faster over the most challenging trails on the planet, this 30mm wide rim is the perfect choice for your enduro bike’s custom wheel build.

Specs:

• MATERIAL: ALUMINIUM
• RIM DIAMETER: 622 mm (29" / 700C)
• INNER WIDTH: 30 mm
• OUTER WIDTH: 35 mm
• REFERENCE DIAMETER ERD: 601 mm
• NET WEIGHT: 570 g
• DECAL TYPE: Vinyl
• BRAKE INTERFACE: Disc
• NUMBER OF HOLES: 28
• BORE TYPE: Non-Eyelet (PHR washer)
• RECOMMENDED SYSTEM WEIGHT MAX: 130 kg
• ASTM CLASSIFICATION: 4
• OPTIONAL: Tubeless tape 32 mm / Tubeless valve MTB 32 mm

Incredibly versatile and easily serviceable hub with a proven reputation for bullet proof quality time and time again. The 6 anodised colours throughout the range give the ultimate in bike customisation.

Features:

• Sealed stainless Steel cartridge bearings throughout
• Hub shell machined from a single forged aluminium billet
• Standard 6 bolt disc fitting
• Larger spoke flange to enable stiffer wheel builds
• Unsurpassed reliability
• Available in QR, 9mm, 12mm, 15mm and 20mm

Specification:

• Available Black, Silver, Red, Blue, Purple and Orange
• Available in 24, 28, 32 and 36 hole drillings
• Conversions available for QR, 9mm, 12mm, 15mm, 20mm, Torq and Boost
• Weight QR - 187g, 9mm - 184g, 15mm - 181g, 20mm - 173g
• Machined from forged 2014 T6 Aluminium billet

Incredibly versatile and easily serviceable hub with a proven reputation for bullet proof quality time and time again. The 6 anodised colours throughout the range give the ultimate in bike customisation.

Features:

• 10, 11 and 12 speed compatible
• Sealed stainless Steel cartridge bearings throughout
• Hub shell machined from a single forged aluminium billet
• Standard 6 bolt disc fitting
• 4 Pawl ratchet system with 44 tooth engagement (8.2 deg)
• Larger spoke flange to enable stiffer wheel builds
• Unsurpassed reliability
• Available in 135mm and 142mm widths

Specification:

• Now available with Shimano MicroSpline freehub body
• Available Black, Silver, Red, Blue, Purple and Orange
• Available in 24, 28, 32 and 36 hole drillings
• Machined from forged 2014 T6 Aluminium billet
• Conversions available for QR, 10mm bolt in, 10mm, 12mm, 142x12mm and 148x12mm thru axles
• Supplied with freehubs to suit 10/11spd Shimano, 12 Speed MicroSpline, Sram XD or Hope cassette
• Aluminium or steel Shimano freehub body options
• Weight: QR - 311g, 142mm - 300g, XD

All Hubs other than DT Swiss and Onyx include a Freehub in the price. This is a
FH06 Freehub - To fit Shimano / Sram SX/NX 10-11speed cassettes.

Check what Freehub body your cassette needs before ordering or contact us for advice.

Race is a very popular double butted spoke. Build up tension is easy. Much less torsion and not as elastic as the Laser spokes are the key points. The Race provides a better shock absorption thanks to a thinner middle section than the one of a non-butted spokes. Dealers say about this traditional spoke: “Never change a winning team…”

Specification:

• Weight: 14G (64 pcs x 260 mm lg) 363g
• Quality: Stainless
• Strength on middle section: 1300 N/mm2
• Length: 135-310mm
• Diameter: 14G 2.0 - 1.8 - 2.0mm
• Recommended for: Race, Mountain, Downhil

Aluminium is the material of choice for higher performance. For this purpose, Sapim has chosen the highest aluminum grade possible (7075 T6) for this sort of usage. It combines light weight, strength and corrosion resistance. The anodized surface treatment provides various color possibilities.

We offer aluminium nipples in: silver, black, red, orange, gold, blue, green and purple. Sapim’s state of the art manufacturing process ensures the best quality available on the market. As a consequence Sapim’s Aluminium nipples has become the benchmark in the market.

Features:

Coating: Coating is applied on all aluminium nipples. The coating is applied on the thread and on the nipple. Friction between both spoke and nipple and rim and nipple is signifi cantly reduced. Coating also seals the surface reducing corrosion. This is now standard in Sapim’s production. Advantages:

• Silent, effective truing with no more squeaks
• Virtually torsion free spokes
• High tension wheels without problems
• No over tight nipples on spoke threads
• No more oily and dirty wheels
• Just efficient dry working and clean hands
• No unnecessary cleaning
• Wheels are easier to true

Specification:

• 64 pcs weight Polyax Aluminium 12mm 19.30 g
• 64 pcs weight Polyax Aluminum 14mm 21.82 g
• 64 pcs weight Polyax Aluminium 16mm 24.80 g

See our selection of coloured valves.
