Antidote CarbonJack 29 Frameset - Ex-Display Custom Paint - Only One Large Available

Name: Antidote CarbonJack 29 Frameset - Ex-Display Custom Paint - Only One Large Available
Brand: Antidote
SKU: Carbonjacklarge1
Price: 2899.00 GBP
Availability: LimitedAvailability

Build Your Dream Enduro Machine: The Antidote Carbonjack 29 Frameset - Ex-Display showbike

The Antidote Carbonjack 29 frameset is a masterpiece of design and engineering, crafted by hand in Poland for the rider who demands uncompromising performance and a truly unique aesthetic. Far from a mass-produced product, this frameset is a testament to meticulous craftsmanship and a passion for pushing the boundaries of mountain bike technology. It provides the perfect, high-performance canvas for your ultimate custom enduro or all-mountain build.

With its striking raw carbon finish and futuristic lines, the Carbonjack isn't just a frame—it's a statement, offering a ride quality that is as impressive as its looks.

The Antidote Carbonjack 29 frameset is the definitive choice for the rider seeking a bespoke, high-performance platform that stands out from the crowd. It’s an elite-level frame with a unique soul, built for pure riding.

click here to see finance examples or £67.80 per month

FINANCE OPTIONS

Consumer credit services are only available to over 18s and subject to status

To see how much this would cost on finance enter Deposit or use slider below

10%

31%

USE THE FINANCE BUTTON AFTER CHECKOUT TO APPLY FOR FINANCE

Months	12	24	36	48
Purchase Cost	£2,899.00	£2,899.00	£2,899.00	£2,899.00
APR	11.90%	11.90%	11.90%	11.90%
Deposit %	10.00%	10.00%	10.00%	10.00%
Deposit amount	£290.00	£290.00	£290.00	£290.00
Loan amount	£2,609.00	£2,609.00	£2,609.00	£2,609.00
Pay per month	£230.94	£121.96	£85.78	£67.80
Total payable	£3,061.28	£3,217.04	£3,378.08	£3,544.40

THE DETAIL

Handmade Carbon Fibre Construction: Each Carbonjack frameset is built by hand in Antidote’s Polish factory, using a unique composite blend that includes Vectran fibres for enhanced strength and superior impact resistance. This results in a frameset that is both lightweight and incredibly durable, backed by the integrity of a small-batch, artisanal process.

Patented FDS Suspension System: At the core of the frame is Antidote’s proprietary Floating Damping System (FDS). This unique 150mm travel platform compresses the rear shock from both ends, creating a sensitive and highly efficient suspension feel. The shock is mounted perpendicularly within the frame, ensuring seamless access to all your damping and rebound adjustments while keeping it shielded from trail debris.

Balanced Enduro Geometry: The Carbonjack 29 is designed to be a versatile and capable all-rounder. With a well-balanced 65-degree head tube angle and a solid 450mm chainstay length across all sizes, it offers stability at speed without sacrificing a playful and agile feel on the trail.

Modern Standards & Smart Features: The frame is designed with practicality in mind, featuring a traditional threaded bottom bracket (TBB) for easy maintenance and long-term durability. It comes with integrated chainstay and downtube protection, internal cable routing with guided tubes for easy installation, and is compatible with Boost 12x148mm rear axles.

Unrivalled Attention to Detail: Every element of the Carbonjack is carefully considered, from the raw carbon finish to the CNC-machined anodised links and titanium bolts. With ample space for a water bottle in the front triangle, this is a frameset that combines exotic performance with everyday usability.

SPECIFICATIONS

Wheel size: 29″
FDS Suspension
Rear Travel 150 mm
Shock length: 210×55 mm
Recommended fork 160-170 mm
Recommended fork offset: shortest available
12 x 148mm rear spacing
Threaded BB or press-fit 92
ISCG 05 Mount
2.6″ tire clearance
Seatpost diameter: 30,9 mm
Headset: Semi-integrated 1 1/8” – 1,5” (Frustum ZS – 44,00mm x 55,95mm)
Material: Monocoque Carbon & Vectran Composite
Bolts: Ti & Aerospace aluminium alloys
Links: 7075 T6 Anodized CNC
MAX LLU all bearings
Integrated seatpost clamp
Custom Flat/PM 180 or 203 mm brake adapter
Lifetime warranty for the first owner

Frame Material: Handmade carbon fibre in Poland. Some sources mention a composite with Vectran fibres for added strength and durability. The visible raw carbon finish is a unique aesthetic.

Suspension:

Proprietary FDS (Floating Damping System) suspension platform.

150mm of rear travel.

Designed for a 160mm or 170mm fork.

A unique shock placement where the shock is compressed from both ends by the suspension links. This makes the bike a "floating shock" design, and it's placed perpendicularly to the frame, giving easy access to adjustments.

Geometry:

Aimed at the enduro/all-mountain category.

Head tube angle: 65 degrees.

Chainstay length: A relatively long 450mm across all sizes.

The manufacturer talks about a "Golden Ratio Geometry" to balance the rider's weight.

Frame Details:

Threaded bottom bracket (BSA 73mm), or press-fit option.

Boost 12x148mm rear axle spacing.

Internal cable routing with tubes for easy maintenance.

Extensive integrated frame protection (chainstay, downtube).

There is room for a water bottle inside the front triangle.

Handmade titanium bolts and anodised CNC links.
