| Feature |
Specification |
Notes |
Notes |
| Wheel Size |
27.5" (ISO 584mm) |
Also known as 650b. |
Designed for aggressive riding and high-impact environments. |
| Intended Use |
Downhill (DH) Racing, Aggressive Enduro, E-Bike |
Engineered for the most demanding terrain. |
Features reinforced spoke holes for enhanced durability. |
| Rim Material |
Carbon Fibre |
Features reinforced rim beads and spoke holes. |
Optimised for 2.3" to 2.5" modern trail tyres. |
| Internal Rim Width |
31mm |
Optimised for 2.4" to 2.6" wide tyres. |
Low-profile depth for strength and ride quality. |
| External Rim Width |
?38mm |
Varies slightly, based on rim profile. |
Available as a pair or in a mixed (MX) configuration. |
| Asymmetric Offset |
4mm |
Improves spoke bracing angle and tension balance. |
Weights are based on a DT Swiss 350 hub build (29" and MX). |
| Spoke Count |
32 per wheel |
3-cross lacing pattern for strength. |
Highly reliable, low-maintenance hub with J-bend spokes. |
| Spokes |
DT Swiss Competition Race or Sapim D-Lite |
Double-butted for an optimal strength-to-weight ratio. |
Uses 28 double-butted J-bend spokes. |
| Nipples |
Sapim Secure Lock Alloy |
External nipple access for easy truing and servicing. |
Standard Mountain Bike Boost axle spacing. |
| Hub Brand |
Chris King ISO |
Available in multiple anodised colours (typically Black/Red). |
Options available, please check specific stock. |
| Front Axle Standard |
20mm�Thru-Axle�110mm |
Standard DH non-Boost spacing. Some older models may be 15mm�110mm (Boost trail). |
Compatible with most modern 11/12-speed drivetrains. |
| Rear Axle Standard |
12mm�Thru-Axle�157mm |
Standard DH/Super Boost rear spacing. Some listings show 12mm�148mm (Boost trail). Confirm before purchase. |
|
| Freehub Body Options |
SRAM XD, Shimano HG |
Allows compatibility with various drivetrains. |
|
| Brake Compatibility |
6-Bolt Disc |
Standard interface for DH brake rotors. |
|
| Tyre Compatibility |
Tubeless Ready (Clincher) |
Comes pre-taped with valves installed. |
|
| Valve Type |
Presta |
Standard bicycle valve. |
|
| Approximate Wheelset Weight |
2,050g (Chris King Hubs) |
Weight includes rim tape and valves. |
|
| Rim Only Weight |
530g |
Weight for a single 27.5" carbon rim. |
|
| Warranty |
Lifetime |
Reserve's comprehensive, no-nonsense warranty. |
|
| Typical UK RRP |
?�1,790.00�-��2,499.00 |
Pricing is a guide and subject to retailer and current availability. |
|
|
| Feature |
Notes |
| Wheel Size |
Also known as 650b. |
| Intended Use |
Engineered for the most demanding terrain. |
| Rim Material |
Features reinforced rim beads and spoke holes. |
| Internal Rim Width |
Optimised for 2.4" to 2.6" wide tyres. |
| External Rim Width |
Varies slightly, based on rim profile. |
| Asymmetric Offset |
Improves spoke bracing angle and tension balance. |
| Spoke Count |
3-cross lacing pattern for strength. |
| Spokes |
Double-butted for an optimal strength-to-weight ratio. |
| Nipples |
External nipple access for easy truing and servicing. |
| Hub Brand |
Available in multiple anodised colours (typically Black/Red). |
| Front Axle Standard |
Standard DH non-Boost spacing. Some older models may be 15mm�110mm (Boost trail). |
| Rear Axle Standard |
Standard DH/Super Boost rear spacing. Some listings show 12mm�148mm (Boost trail). Confirm before purchase. |
| Freehub Body Options |
Allows compatibility with various drivetrains. |
| Brake Compatibility |
Standard interface for DH brake rotors. |
| Tyre Compatibility |
Comes pre-taped with valves installed. |
| Valve Type |
Standard bicycle valve. |
| Approximate Wheelset Weight |
Weight includes rim tape and valves. |
| Rim Only Weight |
Weight for a single 27.5" carbon rim. |
| Warranty |
Reserve's comprehensive, no-nonsense warranty. |
| Typical UK RRP |
Pricing is a guide and subject to retailer and current availability. |
|
|
