Evil Insurgent LS - Space Bot

Name: Evil Insurgent LS - Space Bot
Brand: Evil
SKU: evilinsulsbolt
Price: 4191 GBP
Availability: InStock

Introducing the Evil Insurgent LS Frameset: The Ultimate Bike Park Battering Ram

The Evil Insurgent LS frameset is your rolling battering ram, engineered to dominate bike parks and savage downhill trails. This is Evil's longest-travel and slackest platform, offering 168mm of rear suspension and the versatility of a mixed-wheel (MX) setup with a 170mm fork for added stability, or a full 27.5" platform with a 180mm fork for mind-melting agility. The Insurgent LS isn't just a frame; it's a shape-shifter built for the long send, ready to mop up your mistakes and crack open new possibilities on the gnarliest terrain.

The Insurgent LS combines aggressive travel with an uncanny ability to turn even the most battered bike park into a playground for ripping laps and dusty grins.

The Evil Insurgent LS frameset is the ultimate choice for riders who live for bike park laps, rough race tracks, and combining speed with unadulterated fun. Choose your weapon and let gravity be your guide.

CHOOSE OPTIONS

Size

£2,958.00

Build Kits

£1,433.00

Shock

£0.00

Fork

£0.00

Wheels

-£200.00

BIKE PROTECTION

Frame - Fully Fitted (£250.00)

Fork - Fully Fitted (£60.00)

was £5,510.00

Available to order

£4,191.00

ADD TO ORDER

e: / t: 01323 737320

click here to see finance examples or £123.98 per month

FINANCE OPTIONS

Consumer credit services are only available to over 18s and subject to status

To see how much this would cost on finance enter Deposit or use slider below

10%

50%

USE THE FINANCE BUTTON AFTER CHECKOUT TO APPLY FOR FINANCE

Months	12	24	36
Purchase Cost	£4,191.00	£4,191.00	£4,191.00
APR	11.90%	11.90%	11.90%
Deposit %	10.02%	10.02%	10.02%
Deposit amount	£420.00	£420.00	£420.00
Loan amount	£3,771.00	£3,771.00	£3,771.00
Pay per month	£333.80	£176.27	£123.98
Total payable	£4,425.60	£4,650.48	£4,883.28

THE DETAIL

168mm Rear Suspension: This delivers massive travel for absorbing huge hits and maintaining composure on the most aggressive trails. It comes with a RockShox Super Deluxe Coil Ultimate shock.

Versatile Wheel Configuration: Choose between an MX (29" front / 27.5" rear) setup with a 170mm fork (586mm A-C) for stability, or a full 27.5" platform with a 180mm fork (577mm A-C) for maximum agility.

Carbon Construction: It is crafted from Evil's durable carbon fibre, providing a lightweight yet robust foundation for aggressive riding.
UDH Compatible: Features the SRAM Universal Derailleur Hanger for easy replacement and broad compatibility with modern drivetrains.

Wheelie Short Chainstays (430mm) promote effortless wheelies, playful manuals, and a dynamic ride feel despite their long travel.

Adjustable Geometry (Flip Chips): Fine-tune your ride by switching between LOW mode for everyday trail-slaying and XLOW mode for a gravity-fed, park-eating experience.

Integrated Sag Meter: Quickly and accurately dial in your suspension for optimal performance (hits at the 30% mark).

Calm and Collected Drivetrain: This drivetrain features a rubber sound-cancelling chainstay protector and an integrated chain guide to ensure a silent and deadly ride.

Internal Cable Routing: Fully guided for clean looks, hassle-free maintenance, and cable protection.

Trunnion Shock Spacer Capture: Eliminates fiddling with trunnion shock spacers by capturing them in the linkage for easier shock installation.

Super Boost Rear Axle Spacing (157mm): Ensures a stiff rear end for holding lines and landing those "uh-oh" moments.

Lifetime Bearing Warranty: Evil's renowned pivot bearings are backed by a lifetime warranty for original owners, ensuring silky-smooth pivot action.

Additional Specs: 73mm threaded BB, 30.9mm seatpost, 44mm fork offset, Max 27.5" x 2.6" rear tire, Post Mount 180mm rear brake.
Available Colors: Space Bot.

Available Sizes: Small, Medium, Large, XLarge.

SPECIFICATIONS

	GX I9 Hydra	XT I9 Hydra	X01 I9 Hydra
Frame:	Insurgent	Insurgent	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset	Works Components 1 Degree Angleset	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black	Poly Spacers 5mm black	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick 7075 Alloy, Backsweep: 8deg, Upsweep: 5deg Clamp:35mm, Rise: 35mm, Width: 810mm	Evil Boomstick 7075 Alloy, Backsweep: 8deg, Upsweep: 5deg Clamp:35mm, Rise: 35mm, Width: 810mm	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm	Evil 12 Gauge Stem, Length: 35mm	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on	Evil Palmela Handerson lock-on	Evil Palmela Handerson lock-on
Brake - Front:	SRAM Code RSC	XT M8120 4-POT	SRAM Code RSC
Brake - Rear:	SRAM Code RSC	XT M8120 4-POT	SRAM Code RSC
Rotor - Front:	SRAM Center Line, 200mm	Shimano 203mm	SRAM Center Line, 200mm
Rotor - Rear:	SRAM Center Line, 180mm	Shimano 203mm	SRAM Center Line, 180mm
Brake Adapter:	NA	NA	NA
Shifter:	SRAM GX Eagle, 12sp	Shimano XT 12spd	SRAM X01 Eagle, 12sp
Rear Derailleur:	SRAM GX Eagle, 12sp	Shimano XT 12spd	SRAM X01 Eagle, 12sp
Cassette:	SRAM XG-1275-B1 Eagle, 10-52T, 10,12,14,16,18,21,24,28,32,36,42,52	Shimano XT 10-51t	SRAM XG-1295 Eagle, 10-52T
Chain:	SRAM GX Eagle w/Powerlock	Shimano XT 12spd	SRAM X01 Eagle w/Powerlock
Crankset:	SRAM GX Eagle DUB, SUPERBOOST+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar	Shimano XT M8120 170mm	SRAM X01 Eagle DUB, SuperBoost+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar
Bottom Bracket:	SRAM DUB 73mm BSA	Shimano XT MT800	SRAM DUB 73mm BSA
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3	Maxxis Minion DHF EXO TR, 27.5x2.3	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant	Stan's No Tubes Tubeless Sealant	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro	WTB Volt Pro	WTB Volt Pro
Note:	Specifications are subject to change without notice	Specifications are subject to change without notice	Note:

	XTR I9 Hydra	X01 I9 Hydra
Frame:	Insurgent	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on	Evil Palmela Handerson lock-on
Brake - Front:	Shimanio XTR 4-POT	SRAM Code RSC
Brake - Rear:	Shimanio XTR 4-POT	SRAM Code RSC
Rotor - Front:	Shimano 203mm	SRAM Center Line, 200mm
Rotor - Rear:	Shimano 180mm	SRAM Center Line, 180mm
Brake Adapter:	NA	NA
Shifter:	Shimano XTR 12 Spd	SRAM X01 Eagle AXS, 12sp
Rear Derailleur:	Shimano XTR 12 Spd	SRAM X01 Eagle AXS, 12sp
Cassette:	Shimano XTR 10-51T	SRAM XG-1295 Eagle, 10-52T
Chain:	Shimano XTR 12 Spd	SRAM X01 Eagle w/Powerlock
Crankset:	Shimano XTR 170mm	SRAM X01 Eagle DUB, SuperBoost+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar
Bottom Bracket:	Shimano XTR	SRAM DUB 73mm BSA
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro	WTB Volt Pro
Note:	Note:	Note:

	GX I9 Hydra
Frame:	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick 7075 Alloy, Backsweep: 8deg, Upsweep: 5deg Clamp:35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on
Brake - Front:	SRAM Code RSC
Brake - Rear:	SRAM Code RSC
Rotor - Front:	SRAM Center Line, 200mm
Rotor - Rear:	SRAM Center Line, 180mm
Brake Adapter:	NA
Shifter:	SRAM GX Eagle, 12sp
Rear Derailleur:	SRAM GX Eagle, 12sp
Cassette:	SRAM XG-1275-B1 Eagle, 10-52T, 10,12,14,16,18,21,24,28,32,36,42,52
Chain:	SRAM GX Eagle w/Powerlock
Crankset:	SRAM GX Eagle DUB, SUPERBOOST+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar
Bottom Bracket:	SRAM DUB 73mm BSA
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro
Note:	Specifications are subject to change without notice

	XT I9 Hydra
Frame:	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick 7075 Alloy, Backsweep: 8deg, Upsweep: 5deg Clamp:35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on
Brake - Front:	XT M8120 4-POT
Brake - Rear:	XT M8120 4-POT
Rotor - Front:	Shimano 203mm
Rotor - Rear:	Shimano 203mm
Brake Adapter:	NA
Shifter:	Shimano XT 12spd
Rear Derailleur:	Shimano XT 12spd
Cassette:	Shimano XT 10-51t
Chain:	Shimano XT 12spd
Crankset:	Shimano XT M8120 170mm
Bottom Bracket:	Shimano XT MT800
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro
Note:	Specifications are subject to change without notice

	X01 I9 Hydra
Frame:	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on
Brake - Front:	SRAM Code RSC
Brake - Rear:	SRAM Code RSC
Rotor - Front:	SRAM Center Line, 200mm
Rotor - Rear:	SRAM Center Line, 180mm
Brake Adapter:	NA
Shifter:	SRAM X01 Eagle, 12sp
Rear Derailleur:	SRAM X01 Eagle, 12sp
Cassette:	SRAM XG-1295 Eagle, 10-52T
Chain:	SRAM X01 Eagle w/Powerlock
Crankset:	SRAM X01 Eagle DUB, SuperBoost+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar
Bottom Bracket:	SRAM DUB 73mm BSA
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro
Note:	Note:

	XTR I9 Hydra
Frame:	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on
Brake - Front:	Shimanio XTR 4-POT
Brake - Rear:	Shimanio XTR 4-POT
Rotor - Front:	Shimano 203mm
Rotor - Rear:	Shimano 180mm
Brake Adapter:	NA
Shifter:	Shimano XTR 12 Spd
Rear Derailleur:	Shimano XTR 12 Spd
Cassette:	Shimano XTR 10-51T
Chain:	Shimano XTR 12 Spd
Crankset:	Shimano XTR 170mm
Bottom Bracket:	Shimano XTR
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro
Note:	Note:

	X01 I9 Hydra
Frame:	Insurgent
Shock:	Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Headset:	Works Components 1 Degree Angleset
Headset Spacers:	Poly Spacers 5mm black
Fork:	Rockshox ZEB Ultimate 27.5, Charger 2.1 RC2, 180mm Travel, 44mm Offset (170mm in 29")
Handlebar:	Evil Boomstick Carbon, Backsweep: 8, Upsweep: 5 Clamp: 35mm, Rise: 35mm, Width: 810mm
Stem:	Evil 12 Gauge Stem, Length: 35mm
Grips:	Evil Palmela Handerson lock-on
Brake - Front:	SRAM Code RSC
Brake - Rear:	SRAM Code RSC
Rotor - Front:	SRAM Center Line, 200mm
Rotor - Rear:	SRAM Center Line, 180mm
Brake Adapter:	NA
Shifter:	SRAM X01 Eagle AXS, 12sp
Rear Derailleur:	SRAM X01 Eagle AXS, 12sp
Cassette:	SRAM XG-1295 Eagle, 10-52T
Chain:	SRAM X01 Eagle w/Powerlock
Crankset:	SRAM X01 Eagle DUB, SuperBoost+, 170mm, Direct Mount 32t, 56.5mm Chainline, Lunar
Bottom Bracket:	SRAM DUB 73mm BSA
Wheelset - Front:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Wheelset - Rear:	Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 157x12mm
Tire - Front:	Maxxis Minion DHF EXO TR, 27.5x2.5 (29x2.5")
Tire - Rear:	Maxxis Minion DHF EXO TR, 27.5x2.3
Tubes:	Stan's No Tubes Tubeless Sealant
Seatpost:	Bike Yoke Revive, S:125mm, M: 160mm, L:185mm XL: 213mm
Saddle:	WTB Volt Pro
Note:	Note:
