Hope F22 Pedals

Name: Hope F22 Pedals
Brand: Hope
SKU: PDF22Nz
Price: 128.65 GBP
Availability: LimitedAvailability

Hope F22 Flat Pedals - CNC Machined Aluminium - Dual Concave Profile - Ultimate Grip

The Hope F22 Flat Pedals are the culmination of a decade of expertise, taking the proven durability of the F20 and enhancing it with a completely redesigned platform for modern riding. Fully CNC machined in Barnoldswick, UK, the F22 offers a potent blend of strength, low weight, and supreme grip, making it a perfect upgrade for Enduro, Downhill, and all-mountain riding.

The key to the F22's performance is the larger, dual concave platform (105mm x 102mm usable area), which is thinner in the centre (14mm) and thicker on the edges (17mm). This profile, enhanced by an all-new pin layout, cups your shoe for a superior, 'planted' feeling.

Grip is provided by eleven pins per side with a unique hexagonal head for extra bite and improved resistance to side loads. The pin length is adjustable using supplied spacers, allowing you to fine-tune the level of concave grip to your preference. Crucially, the highly-stressed edge pins are reverse-loaded, making them easier to remove and replace even after a severe rock strike.

Internally, the F22 retains the proven layout of its predecessor, featuring three high-quality cartridge bearings and one IGUS bush. Paired with a high-strength Cr-Mo steel axle and robust internal/external sealing, these pedals are built to endure the worst of the UK's weather. They are fully serviceable and rebuildable, ensuring exceptional long-term value.

CHOOSE COLOUR

Black

Blue

Orange

Purple

Red

Silver

Smoke

was £155.00

Price (select options)

£128.65

e: / t: 01323 737320

THE DETAIL

UK Manufactured: Precision CNC-machined in Hope’s Barnoldswick factory.

Dual Concave Platform: Thinner in the centre (14mm) for a deeply planted feel and superior foot support.

Eleven Adjustable Pins Per Side: Unique hexagonal pins deliver extreme bite and can be adjusted in height with spacers.

Reverse-Loaded Pins: Easier to remove and replace after impacts, preventing them from loosening on the trail.

Proven Durability: Features a high-strength Cr-Mo axle running on three sealed cartridge bearings and an IGUS bush.

Fully Serviceable: Designed for longevity, allowing for complete rebuilds and easy maintenance.

SPECIFICATIONS

Specification	Detail	Notes
Model	Hope F22 Flat Pedal (Pair)	Successor to the celebrated Hope F20 model.
Body Material	CNC Machined 2014 T6 Aluminium	High-strength alloy, manufactured in Barnoldswick, UK.
Axle Material	High-Strength Cr-Mo Steel (Heat Treated and Plated)	Revised design for improved strength and impact resistance.
Platform Dimensions	Approx. 105mm x 102mm (Usable Area)	Increased surface area compared to the F20 for better shoe support.
Pedal Thickness	14mm (Centre) to 17mm (Outer Edge)	Creates an aggressive, dual-concave profile.
Pin Quantity	11 pins per side (22 pins per pedal)	New pin design for better grip and adjustable height.
Pin Features	Unique Hexagonal Head, Reverse-Loaded, Height Adjustable	Supplied with spacers to fine-tune pin height and concavity.
Internals	3x Cartridge Bearings and 1x IGUS Bush	Proven internal layout for smooth, long-term durability.
Sealing	Internal and External Sealing	Excellent weather protection against dirt and debris ingress.
Weight (Pair)	360g (Claimed)	Very lightweight for a large, all-aluminium platform.
Crank Interface	9/16" standard threaded mount	Compatible with most standard mountain bike cranks.
Serviceability	Fully Serviceable and Re-buildable	Spare parts are readily available for a full overhaul.
Colour Options	Available in multiple Hope signature anodised colours.	Black, Silver, Blue, Red, Orange, Purple, Smoke.

Specification	Detail
Model	Hope F22 Flat Pedal (Pair)
Body Material	CNC Machined 2014 T6 Aluminium
Axle Material	High-Strength Cr-Mo Steel (Heat Treated and Plated)
Platform Dimensions	Approx. 105mm x 102mm (Usable Area)
Pedal Thickness	14mm (Centre) to 17mm (Outer Edge)
Pin Quantity	11 pins per side (22 pins per pedal)
Pin Features	Unique Hexagonal Head, Reverse-Loaded, Height Adjustable
Internals	3x Cartridge Bearings and 1x IGUS Bush
Sealing	Internal and External Sealing
Weight (Pair)	360g (Claimed)
Crank Interface	9/16" standard threaded mount
Serviceability	Fully Serviceable and Re-buildable
Colour Options	Available in multiple Hope signature anodised colours.

Specification	Notes
Model	Successor to the celebrated Hope F20 model.
Body Material	High-strength alloy, manufactured in Barnoldswick, UK.
Axle Material	Revised design for improved strength and impact resistance.
Platform Dimensions	Increased surface area compared to the F20 for better shoe support.
Pedal Thickness	Creates an aggressive, dual-concave profile.
Pin Quantity	New pin design for better grip and adjustable height.
Pin Features	Supplied with spacers to fine-tune pin height and concavity.
Internals	Proven internal layout for smooth, long-term durability.
Sealing	Excellent weather protection against dirt and debris ingress.
Weight (Pair)	Very lightweight for a large, all-aluminium platform.
Crank Interface	Compatible with most standard mountain bike cranks.
Serviceability	Spare parts are readily available for a full overhaul.
Colour Options	Black, Silver, Blue, Red, Orange, Purple, Smoke.
