Mondraker Crafty CARBON XR - Mars

Name: Mondraker Crafty CARBON XR - Mars
Brand: Mondraker
SKU: 010.25370z
Price: 7519.2 GBP
Availability: LimitedAvailability

Introducing the 2025 Mondraker Crafty Carbon XR: The Ultimate E-Enduro Machine

Welcome to a new generation of authentic e-Enduro: the 2025 Mondraker Crafty Carbon XR. Engineered for riders who constantly push the limits, this latest evolution of Mondraker’s most successful e-Bike is more CRAFTY than ever before. It blends unmistakable identity with dramatically increased performance, agility, and pedalling assistance, making it a true trail beast.

The Crafty Carbon XR is built around a full Crafty Stealth Air Carbon frame, boasting 150mm of updated Zero Suspension System travel and Mondraker's renowned Forward Geometry. Setting it apart, the XR has an elite Öhlins RXF 38 M.2 29 170mm fork and an Öhlins TTX22M.2 coil rear shock, delivering unparalleled damping performance and control on the gnarliest terrain. Powering your adventure is Bosch’s revamped Performance Line CX (Smart System) motor, paired with a 600Wh internal removable battery (with optional 250Wh Powermore extender for extended range).

The 2025 Mondraker Crafty Carbon XR is the no-compromise e-Enduro bike for riders who demand the absolute pinnacle of performance, components, and technology to conquer any trail.

CHOOSE SIZE

S (Out of stock)

L (Out of stock)

XL (Out of stock)

was £9,399.00

Price (select options)

£7,519.20

e: / t: 01323 737320

click here to see finance examples or £148.12 per month

FINANCE OPTIONS

Consumer credit services are only available to over 18s and subject to status

To see how much this would cost on finance enter Deposit or use slider below

10%

50%

USE THE FINANCE BUTTON AFTER CHECKOUT TO APPLY FOR FINANCE

Months	6	12	24	36	48	60
Purchase Cost	£7,519.20	£7,519.20	£7,519.20	£7,519.20	£7,519.20	£7,519.20
APR	0.00%	0.00%	7.90%	7.90%	7.90%	11.90%
Deposit %	10.00%	10.00%	10.00%	10.00%	10.00%	10.00%
Deposit amount	£752.00	£752.00	£752.00	£752.00	£752.00	£752.00
Loan amount	£6,767.20	£6,767.20	£6,767.20	£6,767.20	£6,767.20	£6,767.20
Pay per month	£1,127.87	£563.93	£304.93	£210.91	£164.04	£148.12
Total payable	£7,519.22	£7,519.16	£8,070.32	£8,344.76	£8,625.92	£9,639.20

THE DETAIL

Full Carbon Frame Construction: Crafty Stealth Air full Carbon frame (with 150mm travel) for ultimate strength, lightness, and responsiveness, featuring updated Zero Suspension System, Forward Geometry, and internal removable battery integration.

Fork: Öhlins RXF 38 M.2 29, 170mm travel, TTX18 Twin Tube cartridge, e-bike tuned, with extensive adjustability.

Rear Shock: Öhlins TTX22M.2 Coil, 185x55mm, offering superior small-bump compliance and big-hit capability, with high/low-speed compression and rebound adjustments.

Bosch Performance Line CX Motor (Smart System): Lighter, more efficient, and quieter, delivering 85Nm of torque and 600W max power for seamless and powerful pedal assistance. Powered by a Bosch Powertube 600Wh internal removable battery.

SRAM X0 Eagle AXS Transmission 12-Speed: Top-tier wireless electronic drivetrain for precise, reliable, and durable shifting performance under extreme conditions.

SRAM Maven Silver 4-Piston Brakes: These hugely powerful hydraulic disc brakes have 220mm front and 200mm rear SRAM HS2 CL rotors and steel-backed metallic sintered pads, offering unmatched stopping power and modulation for aggressive riding.

Mavic E-Deemax S 29 Wheelset: Robust 29" wheels with 30mm internal width, tubeless-ready rims, Boost hub spacing, and an XD freehub for reliable performance.

Aggressive Maxxis WT Tires: Front: Maxxis Assegai 29x2.6WT (3C MAXX GRIP, DD protection, DH casing). Rear: Maxxis Minion DHR II 29x2.6 WT (3C MaxxTerra, DD protection). Both tubeless-ready for maximum grip and puncture resistance.

Premium Carbon Cockpit: Onoff S9 Full CNC stem paired with a lightweight Onoff S6 1.0 Carbon handlebar (800mm wide) for precise control.

Onoff Pija Dropper Post: This internally routed dropper post has travel from 140mm to 210mm (size-specific) for optimal riding position on diverse terrain.

Optimised Sizing & Geometry: This model features an intermediate ML frame size among five total sizes (S, M, ML, L, XL), with optimised kinematics and proportional swingarm lengths (455mm/465mm) for a perfect fit and consistent Mondraker "feeling."

Lightweight: Weighs an impressive 22.9 kg (50.48 lbs), making it agile for an e-Enduro bike.

Distinctive Colourway: Finished in a striking Mars / Black colour scheme.

SPECIFICATIONS

Frame: Crafty Stealth Air full Carbon, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Sizes: S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

Rear shock: Öhlins TTX22M.2 185x55mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings

Shock settings: C10 compression, R20 rebound. Spring rate: S size 411 lbs, size M 457 lbs, ML size 502 lbs, L size 548 lbs, XL size 605 lbs

Fork: Öhlins RXF 38 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber

Headset: Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock

Stem: Onoff S9 30mm 0º, Full CNC, 31.8mm barbore

Handlebar: Onoff S6 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.

Grips: Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size

Seatpost: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)

Saddle: Ergon SM-10

Front brake
Sram Maven Silver, 18 and 19.5-millimeter 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Rear brake: Sram Maven Silver, 18 and 19.5-millimeter 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Brake lever: Sram Maven Silver, SwingLink and lever pivot bushings, tools-free reach adjust

Rims: Mavic E-Deemax S 29, 30mm internal width, Maxtal welded, PFP, tubeless, 28 spokes

Spokes: Mavic straight-pull double butted, contactless lacing

Front hub: Mavic, Boost 15x110mm, IS 6 bolts

Rear hub: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, XD freehub

Front tyre: Maxxis Assegai 29x2.6WT, tubeless ready, 3C MAXX GRIP compound, DD protection, DH casing, 60x2TPI, folding bead

Rear tyre: Maxxis Minion DHR II 29x2.6 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead

Crankset: e*Thirteen Helix Race Carbon E*Spec Plus, All sizes: 160mm

Rings: Sram X-Sync 2 Eagle 34T T-Type, steel, narrow-wide, 104 BCD CL55

Chain: Sram GX Eagle T-Type, 12s, Powerlock

Rear derailleur: Sram X0 Eagle AXS, T-Type, 12s

Shift levers: Sram Eagle AXS Pod MMX, 12s

Casette: Sram XS-1275, 10-52T, T-Type, 12s

Weight: 22.9 kg

Display: Purion 400 / Bosch Mini Remote / Bosch System Controller

Motor: New Bosch Performance Line CX Cruise (25Km/h) SMART SYSTEM (BDU384Y)

Battery: Bosch Powertube 600Wh
